Clinic Medical Ultrasound Equipment Diagnostic Ultrasound Scanner Machine
Product Details:
| Place of Origin: | Guangzhou China |
|---|---|
| Brand Name: | GOLGATHA |
| Certification: | CE/ISO |
| Model Number: | GGT – 3011 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | The price is negotiable |
| Packaging Details: | Conventional packing |
| Delivery Time: | 1-30 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1-10000 PCS per month |
Product Description
| Type: | Ultrasound Scanner | Group: | Human |
|---|---|---|---|
| Display Mode: | B, B+B, B+M, M | Magnification: | X1.0, X1.2, X1.5, X2.0 |
| Image Storage: | 20 Frames | N.W: | 30kg. |
High Light: |
medical ultrasound machine, ultrasound scan equipment |
||
Applicable range
The device is applicable for hospitals and clinics for examining liver, GB, spleen, kidney, pancreas, heart, bladder, uterus, etc.
Features
·The image can be displayed in real time, frozen, amplified, black- white reversed, up and down conversed and shift depth in real time.
· Video output is standard PAL and VGA; it is easily accessed to the equipment, such as the large screen monitor, videocassette recorder, video image printer, etc.
·Soft keyboard and track ball to make operation faster, convenient and flexible.
·The device is trolley structured with plastic cover. Switch power is used without working frequency transformer.
FPGA and SMT in the device make the device high integrated, small volume and light weight.
·The device passed clinical verifications of safety and diagnosis validity in its manufacturing country.
Specifications
| Display Depth (mm) | ≥220 |
| Resolution(mm) | Lateral, ≤3(depth≤80), ≤4(80<depth≤130); Axial, ≤2(depth≤80), ≤3(80<depth≤130) |
| Dead Zone (mm) | ≤5 |
| Geometry precision (%) | Horizontal: ≤15; Vertical: ≤10 |
| Monitor screen | 14 inch |
| Display mode | B, B+B, B+M, M |
| Image gray scales | 256 scales |
| Electronic focusing | 4 focuses combination randomly |
| Magnification | x1.0, x1.2, x1.5, x2.0 |
| Cine-loop | 186 or 236 frames |
| Image storage | 20 frames |
| Pseudo-color unit | inside |
| Image reverse | left/right, black/white, up/down |
| Local Zoom | 2 times |
| Depth shift | B, B+B modes real time shift |
| Powder supply | 100V-130V/220V-240V, 50/60Hz |
| Machine dimension (mm) | 510*680*1240 |
Standard Configuration
.Scanner Body: 1pc
·3.5Mhz Convex Probe: 1pc
·Charger with a set of wires: 1set
·Bottle of USG gel: 1pc
·User Manual: 1pc
Optional
·5.0MHz Micro-convex Probe
·6.5MHz Trans-vaginal Probe
·7.5MHz Linear Probe
.Video Printer
.
